YDH.RF.0288

Driven Type:Engine Driven+Standby Unit
Installation:Front Mounted
Voltage
Standby:AC220V,50HZ(60HZ),1PH/AC380V,50HZ,3PH
Engine Driven:DC12V
Compressor(Engine Driven):Valeo TM16
Compressor(Standby Unit):DY507
Controller:Digital, In Cab
Engine Cooling Capacity:-20℃-2600W/8840 BTU/0℃-5250W/17900 BTU
Standby Unit
Motor Power:220V-2.2KW/380V-2.2KW
Peak Current:220V-15A/380V-11A
Running Current:220V-13A/380V-9A
Cooling:-20℃-2691W/9180BTU/0℃-6030W/20574 BTU
Volume of container:15CBM-21CBM(-20℃)
Refrigerant:HFC-R404A,2.2KG
Condenser
Coil:Parallel Flow
Fan No:2
Dimension:1080*510*375 mm
Evaporator
Coil:2
Blower No.:Copper Tube & Aluminum Fin
Air Flow:3100m³/h
Dimension:1260*593*185 mm
