YDH.BS.0065

SOUTH MATCHING MODEL（m）：11.5~12
NORTH MODEL LENGTH（m）：11~12.5
COOLING CAPACITY（kw）：32~34
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：KBQY4-65N,FKX40/655,4NFCY/6TFCT
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~8000
CURRENT (A)：72
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axial flow type
AIRFLOW (m³/h)：~10000
CURRENT (A)：45
DIMENSIONS（mm）：4931x1860x200
Weight of rood-mount unit (kg)：255

CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):117
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Optional
