YDH.BS.0064

SOUTH MATCHING MODEL(m):10~12
NORTH MODEL LENGTH(m):11~12
COOLING CAPACITY(kw):30~32
REFRIGERANT:R134a
SUPPLY VOLTAGE(V.DC):24
COMPRESSOR MODEL:KBQY4-65N,FKX40/655,4NFCY/6TFCT
EVAPORATOR
TYPE:Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE:Centrifugal type
AIR FLOW (m³/h):~8000
CURRENT (A):72
CONDENSER
TYPE:finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE:Axial flow type
AIRFLOW (m³/h):~10000
CURRENT (A):45
DIMENSIONS(mm):4931x1860x200
Weight of rood-mount unit (kg):245

CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃):18-30(continuously adjustable)
DEFROST TEMPERATURE (℃):1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):117
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Optional
