YDH.RF.0145

Cooling Capacity
0℃/+38℃:5300W/18084Btu
-18℃/+38℃:2950W/10065Btu
Temperature Range:-18℃~+30℃
Voltage:DC24V
Standby Voltage:AC220~240V、380V-3
Defrosting:Hot gas defrosting
Evap. Air Volume:2600m³/h
Refrigerant & Volume:R404a/2.0kg
Compressor
On Road:Model:Carrier QP16,163cc/n
Standby:Brand:HIGHLY
Standby:Dis.:35.6 or 48.8mL/rev
Condenser
Coils:Parallel flow
Fan Qty.:2Pcs
Size:1260*600*415mm
Weight:86kg
Evaporator
Coils:Copper tube and fin
Fan Qty.:3Pcs
Size:1030*570*295mm
Weight:26kg
Recommended Box Size:22-30m³
