YDH.RF.0142

Cooling Capacity
0℃/+38℃:4300W/14672Btu
-18℃/+38℃:2600W/8871Btu
Temperature Range:-18℃~+30℃
Voltage:DC12V
Standby Voltage:AC220~240V、380V-3
Defrosting:Hot gas defrosting
Evap. Air Volume:2600m³/h
Refrigerant & Volume:R404a/2.0kg
Compressor
On Road:Model:Carrier QP16, 163cc/r
Standby:Brand:HIGHLY
Standby:Dis.:35.6 or 48.8mL/rev
Condenser
Coils:Parallel flow
Fan Qty.:2Pcs
Size:1260*600*415mm
Weight:86kg
Evaporator
Coils:Copper tube and fin
Fan Qty.:2Pcs
Size:1010*660*220mm
Weight:23kg
Recommended Box Size:18-25m³
