YDH.RF.0137

Cooling Capacity
0℃/+38℃:3100W/10577Btu
-18℃/+38℃:1750W/5971Btu
Temperature Range:-18℃~+30℃
Voltage:DC24V
Standby Voltage:AC220~240V
Defrosting:Hot gas defrosting
Evap. Air Volume:1750m³/h
Refrigerant & Volume:R404a/1.3kg
Compressor
On Road:Model:Carrier QP16,163cc/r
Standby:Brand:HIGHLY
Standby:Dis.:35.6mL/rev
Condenser
Coils:Parallel flow
Fan Qty.:1Pcs
Size:1150*860*250mm
Weight:69kg
Evaporator
Coils:Copper tube and fin
Fan Qty.:2Pcs
Size:980*570*210mm
Weight:20kg
Recommended Box Size:12-20m³
