YDH.RF.0133

Cooling Capacity
0℃/+38℃:Engine:10752W/36664BTU;6800W/23188BTU
-18℃/+38℃:Standby:15360W/52378BTU;8000W/27280BTU
Temperature Range:-18℃~+30℃
Voltage:DC12V
Defrosting:Hot gas defrosting
Evap. Air Volume:3200m³/h
Refrigerant & Volume:R404a/6.0kg
Electric Compressor
Model:400-BV-23
Dis.:23m³/h
Engine
Model:Yanmar, 3TNV80
Rating:15.2kw
Stand-by
Voltage:380V/3Ph,50Hz/60Hz
Rating:4HP/3.8kw
Product Size
Condenser:1890*935*595mm
Evaporator:1210*635*330mm
Products Weight:580kg
Recommended Box Size:50-60m³
