YDH.PH.0018

Overall Dimensions(Length*Width*Height): 236*147*83mm
Installation Dimension: 154(104)*165mm
Joint Size: quick coupling
High Voltage Connector Model: : HVIL-F3P(16A)-A-1
(Avicoptronics)
Low Voltage Connector Model: PB621-04020(KUM)
Rated Voltage(V): 380
Voltage Range(V): 300~450
Rated Power(W): 6000±10%@10L/min, Tin=0℃
Control Mode: Vehicle relay control
Note: Please refer to the technical specification for the specific parameters.
