YDH.BS.0055

SOUTH MATCHING MODEL（m）：6~6.5
NORTH MODEL LENGTH（m）：6~6.8
COOLING CAPACITY（kw）：12~14
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：KBXY32，DKS32
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~4000
CURRENT (A)：36
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axial flow type
AIRFLOW (m³/h)：~4000
CURRENT (A)：18
DIMENSIONS（mm）：2640x1560x190
Weight of rood-mount unit (kg)：120

CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):54
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Optional
