YDH.BS.0036

City bus（m）：11.5~12.5
COOLING CAPACITY（kw）：30~35
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24DC
COMPRESSOR MODEL：KBXY32， KBQY4-40N，KBQY4-40N，KBQY4-47N，KBQY4-56N
EVAPORATOR
TYPE：Finned tube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~8000
CURRENT (A)：64
CONDENSER
TYPE：finned tube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axial flow type
AIRFLOW (m³/h)：~10000
CURRENT (A)：47
Weight of unit (kg)：225
DIMESIONS:4500x1830x195
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):110
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fusible plugs (℃) :95 Optional
Fresh air device：Standard
