YDH.BS.0030

SOUTH MATCHING MODEL（m）：11~12.5
NORTH MODEL LENGTH（m）：11.5~ 13
COOLING CAPACITY（kw）：32~37
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：FKX40/655、4NFCY
EVAPORATOR
TYPE：Finned tube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~8000
CURRENT (A)：64
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~10000
CURRENT (A)：45
DIMENSIONS（mm）：3050x1860x228
Weight of rood-mount unit (kg)：235
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):115
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Standard
