YDH.BS.0027

SOUTH MATCHING MODEL（m）：8.3~9.5
NORTH MODEL LENGTH（m）：9.2~10.5
COOLING CAPACITY（kw）：26~30
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：FKX40/560、4PFCY
EVAPORATOR
TYPE：Finned tube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~6000
CURRENT (A)：48
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~8800
CURRENT (A)：37
DIMENSIONS（mm）：2830x1845x225
Weight of rood-mount unit (kg)：215
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):89
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Standard
