YDH.BS.0024

SOUTH MATCHING MODEL（m）：12.5~13.5
NORTH MODEL LENGTH（m）：12.5~14
Passenger touring coach（m）：13~14
City bus（m）：12.5~13.5
COOLING CAPACITY（kw）：36~41.5
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：6PFCY
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~8000
CURRENT (A)：64
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~13200
CURRENT (A)：57
Weight of rood-mount unit (kg)：~330
DIMENSIONS（mm）：5290x1830x191
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):121
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Standard
