YDH.BS.0020

SOUTH MATCHING MODEL（m）：9~11
NORTH MODEL LENGTH（m）：10~12
Passenger touring coach（m）： 10.5~12
City bus（m）：10~11
COOLING CAPACITY（kw）：28~32.5
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：FKX40/655，4NFCY，KBQY4-65N
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~8000
CURRENT (A)：48~64
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~8800
CURRENT (A)：37.6
Weight of rood-mount unit (kg)：~297
DIMENSIONS（mm）：4380X1830x193
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):90~108
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Standard
