YDH.BS.0018

SOUTH MATCHING MODEL（m）：83~9.3
NORTH MODEL LENGTH（m）： 88~103
Passenger touring coach（m）：9~10.5
City bus（m）： 8.5~9.5
COOLING CAPACITY（kw）：24~28
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：FKX40/560，4PFCY，KBQY4-56N
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~6000
CURRENT (A)：48
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~8000
CURRENT (A)：37.6
Weight of rood-mount unit (kg)：~239
DIMENSIONS（mm）：3505x1830X193
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):90
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Standard
