YDH.BS.0016

SOUTH MATCHING MODEL（m）：7.5~8.2
NORTH MODEL LENGTH（m）：7.6~8.3
Passenger touring coach（m）：8~8.5
City bus（m）：7.9~8.3
COOLING CAPACITY（kw）：20~24
REFRIGERANT：R134a
SUPPLY VOLTAGE（V.DC）：24
COMPRESSOR MODEL：FKX40/390,4UFCY,F400,KBXY42,KBQY4-40N
EVAPORATOR
TYPE：Finned tube type (rifled copper tube, hydrophilic aluminum foil)
FAN
TYPE：Centrifugal type
AIR FLOW (m³/h)：~3600
CURRENT (A)：34
CONDENSER
TYPE：finnedtube type (rifled copper tube,hydrophilic aluminum foil)
FAN
TYPE：Axialflow type
AIRFLOW (m³/h)：~6600
CURRENT (A)：28.2
Weight of rood-mount unit (kg)：~230
DIMENSIONS（mm）：3505X1675/1830X193
CONDENSER SYSTEM
COMPARTMENT TEMPERATURE (℃）：18-30(continuously adjustable)
DEFROST TEMPERATURE (℃）：1~3
AIR VOLUME AD JUSTMENT:Three-level air volume(manualor digital control)
TOTAL CURRENT (A):65
SAFETY DEVICE
HIGH-PRESSURE SWITCH (MPa) :2.6 OFF
LOW-PRESSURE SWITCH (MPa) :≤0.065 ON
Fresh air device:Optional
